SIM7020E NB IoT Module For Raspberry Pi Pico

$44.95
SKU 92291006

Get your Raspberry Pi Pico connected to the wireless outside world with this SIM7020E NB IoT Module from PMD Way. Free delivery, worldwide.

Supports bands LTE-FDD:B1/B3/B5/B8. Not for USA, Canada!

It supports multiple NB-IoT frequency bands, can be controlled via serial AT commands, and supports communication protocols like HTTP/MQTT/LWM2M/COAP, etc. Due to the advantages of low delay, low power, low cost, and wide coverage, it is the ideal choice for IoT applications such as intelligent instruments, asset tracking, remote monitoring, and so on. External antenna shown is included.

Features:

  • Standard Raspberry Pi Pico header, supports Raspberry Pi Pico series boards
  • UART communication, serial AT commands control, multiple communication protocols support, multiple cloud platform support
  • Integrates 3.7V Li-po battery connector and recharge circuit, allows being powered from external rechargeable Li-po battery, or recharging it in turn
  • 2x LED indicators, for monitoring the module operating status
  • Onboard Nano SIM card slot for NB-IoT specific card
  • Comes with development resources and manual (MicroPython examples)

Supports bands LTE-FDD:B1/B3/B5/B8. Not for USA, Canada!
